Gate Design
Access: Open this function from one of the following locations:
-
Select Mold Design > Runner > Gate Design from the menu bar.
-
Select Runner Design > Gate Design from the Mold Design Guide Toolbar.
Design the melt entrance gate.
General Interaction
The following is the Feature Guide for Gate Design.
|
|
|
Tip: You can open the Feature Guide at any time by right-clicking the mouse in the graphic display area.Required Step 1
: Select the gate options and set the parameters.
Optional Step 1
: Offset the start and end points.
Detailed Interaction
See Options and Results.
