Part Environment - M-View
An M-View (Modeling View) is a user-defined view of entities which includes a profile of display parameters, section parameters, drafting parameters, etc. Visibility, orientation, as well as section-lines can be defined for each view.
New M-View
The Clip Core part from the last exercise will be used.
-
Show the All Entities set and select the M-View tab.
-
Right-click in the M-View tree and select New M-View from the popup menu.
The M-View Feature Guide opens and various editing options can be performed.
