Edit Constraints

New Part

1. Open a New Part File.

2. Open the Sketcher.

   The line toolline tool is activated as the default tool in a new sketch.

3. Draw a horizontal line above the UCS, and then add another horizontal line below the UCS using the same X constraint from the left hand point.


4. DrawDraw the left-hand arc using the end pointsend points of the lines as references.



   1. Move the cursor to define the arc's shape and direction, and click.
