Step 2 - Load Work Part

Note the following:

1. The Assembly structure.
   A mold assembly has been created. This assembly currently consists of Parting sub-assembly.

2. The Mold Design Guide.
   Both guides, Parting and Mold, guide you through the logical steps of the Mold Project process from start to finish.



3. There is also a Parting sub-assembly, which is activated appears in bold by default and will be used first.


   The Parting sub-assembly will later include the work parts and parting faces parts. This helps to organize the split work.

Some functionality may be dependent on the product package. Contact your Reseller if you require a license.
