Parting Faces

Activate 3A

Activate and Deactivate are also useful tools when creating parting faces. This is due to the parting faces being stitched to one other, but not to the part itself.

Apply rounds to the 8 near-vertical edges as shown, using a radius of 1212.

Change the Object color to Green.

At this point, no objects are activated.
