Tilted with Fixed Angle to Axis
-
Edit the procedure.
-
Change the Tool Axis to the Tilted with Fixed Angle to Axis option.
-
Set the Tilt Angle to 45 and make sure it is set to X-Axis.
With this option, the tool axis will be tilted at a fixed angle relative to the chosen axis. The tilt axis can be towards the X, Y, and Z axis or to any line created in the geometry. Tilt axis and surface normal build a plane in which the tool tilts. -
Execute the procedure and switch to Front view.
-
Enter the Navigator to view the results.
The tool is now tilted towards X+ in a constant angle of 45 degrees all along the toolpath (TP). Notice that the CC (touch) point on the surface is maintained while the CL point is moved due to the tilt.
